Pre-Heating Infrared Conveyors

Pre-Heating Infrared Conveyors
Pre-Heating Infrared Conveyors
Send Inquiry
Product Code : PHIC 09
Brand Name : MICRON TECH
Product Description

We are known as a prominent manufacturer and exporter of Pre-Heating Infrared Conveyors. These conveyors are used in dairy industries and ice cream plants for conveying the final products one place to another. Our Pre-Heating Infrared Conveyor is made in conformation with international quality standards by using top quality materials and sophisticated technology. We offer these conveyors to the clients at a reasonable price.

Features:

  • Programmable PLC based controller
  • Easy to install
  • Less power consumption

TECHNICAL SPECIFICATIONS

FULLY AUTOMATIC TWO STAGE PET PREFORM STRETCH BLOW MOULDING MACHINE

Description / Model

STA-500-B

STA-1000-B(HP)

STA-2000-B(HP)

STA-2000-J(HP)

Product Volume

30ml-500ml

50ml-1250ml

200ml-3000ml

200ml-3000ml

Mould Cavity

2 Cavity

2 Cavity

2 Cavity

2 Cavity

Production PER HRS

1800 Pcs - 2000 Pcs

1500 Pcs - 1800 Pcs

1200 Pcs - 1500 Pcs

600 Pcs -800 Pcs

Neck Dia Meter

19 mm - 28 mm

25 mm - 28 mm

28 mm

46 mm - 83 mm

TIE BAR Distance

235mm

285mm

350mm

350mm

Mould Width

225 mm

280 mm

240 mm

340 mm

Mould Thickness

140 mm

150 mm

200 mm

200 mm

Cavity Distance

135 mm

135 mm

185 mm

185 mm

Clamping Stroke

100 mm

150 mm

150 mm

200 mm

Clamping Force

4 TAN

8 TAN

10 TAN

10 TAN

Operation

Hydro-Penu

Hydro-Penu

Hydro-Penu

Hydro-Penu

Electric Heater Power

12 K.W.

15 K.W.

18 K.W.

18 K.W.

Heater Type

Inferd Conveir

Inferd Conveir

Inferd Conveir

Inferd Conveir

Working Pressure

6 Kg - 8 Kg

8 Kg - 10 Kg

8 Kg - 10 Kg

8 Kg - 10 Kg

Blowing Pressure

15 Kg - 18 Kg

30 Kg - 35 Kg

30 Kg - 40 Kg

30 Kg - 40 Kg

Air Consumption

0.9 M3 / MIN

1. M3 / MIN

1. M3 / MIN

1.02 M3 / MIN

Staff Requirement

2 Person

2 Person

2 Person

2 Person

Air Compressor

20 HP - (LP), 52 CFM

20 HP  (LP), 42 CFM

20 HP  (LP), 52 CFM

25 HP (LP), 52 CFM

Area Requirement

30 Mtr

30 Mtr

35 Mtr

35 Mtr

Machine Weight

1500 Kg Approx

1800 Kg Approx

2200 Kg Approx

2500 Kg Approx
