Industrial Conveyor Preheat Ovens

Industrial Conveyor Preheat Ovens
Industrial Conveyor Preheat Ovens
Send Inquiry
Product Code : ICPO 19
Brand Name : MICRON TECH
Product Description

1 Litre Machine With Pre Heating Infrared Conveyor

  • Manual feeding of two performs in to the Kulfy heating oven device for heating
  • Manual insertion of the two heated preforms in the blowing machine
  • Automatic mould clamping and preform stretching
  • Automatic blowing and mould opening
  • Manual injection of the two bottles

TECHNICAL SPECIFICATIONS

SEMI AUTOMATIC PET PREFORM STRETCH BLOW MOULDING MACHINE 500ML-25LTR.BOTTLE  & JAR

Description / Model

ST-500-B(LP)

ST-1000-B(LP)

ST-1000-B(HP)

ST-1000-B(HP)

Product Volume

30ml-500ml

50ml-1250ml

50ml-1250ml

50ml-1250ml

Mould Cavity

2 Cavity

2 Cavity

2 Cavity

4 Cavity

Production PER HRS

500 Pcs , 700 Pcs

600 Pcs , 700 Pcs

1000 Pcs ,1200 Pcs

2000 Pcs , 2400 Pcs

Neck Dia Meter

19 mm - 28 mm

25 mm - 28 mm

25 mm - 28 mm

25 mm- 28 mm

TIE BAR Distance

235mm

285mm

285mm

430mm

Mould Width

225 mm

280 mm

280 mm

420 mm

Mould Thickness

120 mm

140 mm -150 mm

140 mm

140 mm

Cavity Distance

125 mm

135 mm

135 mm

135 mm

Clamping Stroke

100 mm

150 mm

150 mm

150 mm

Clamping Force

2 TAN

4 TAN

4 TAN

8 TAN

Operation

Hydro-Penu

Hydro-Penu

Hydro-Penu

Hydro-Penu

Electric Heater Power

1.5 K.W.

2 K.W.

10 K.W.

10 K.W.

Heater Type

Kulfi-Oven

Kulfi-Oven

Inferd Conveir

Inferd Conveir

Working Pressure

5 Kg - 6 Kg

6 Kg - 8 Kg

6 Kg - 8 Kg

8 Kg - 10 Kg

Blowing Pressure

10 Kg - 12 Kg

12 Kg - 15 Kg

12 Kg - 15 Kg

12 Kg - 30 Kg

Air Consumption

0.4 M3 / MIN

0.5 M3 / MIN

0.8 M3 / MIN

1. M3 / MIN

Staff Requirement

2 Person

2 Person

2 Person

2 Person

Air Compressor

7.5 HP - LP, 20 CFM

10 HP - LP, 35 CFM

15 HP - LP, 38 CFM

20 HP-HP, 42 CFM

Area Requirement

20 Mtr

25 Mtr

30 Mtr

35 Mtr

Machine Weight

500 Kg Approx

600 Kg Approx

700 Kg Approx

800 Kg Approx
